The Edulab 0-15V variable power supply has proved to be extremely popular and the ideal choice for physicists worldwide. It is simply the most advanced power pack available today and with the 5 year warranty it’s a safe investment.
This power supply provides continuosly variable voltage of 0-15V for both AC and slightly smoothed DC. Long switch lift time means that voltage can be switched safely at full load without serious contact wear. Continuously rated output of 8.5A, AC or DC , or added sum of 8.5A
Fully protected, secondary by high speed, micro-processor controlled, resettable electronic trip. Over-current is measured and timed for cases of serious overload and slight overload to decide tripping time This avoids over-sensitive tripping in cases of initial heavy current surge, for example when using lamp bulbs.
Slow-blow fuse protection for primary transformer. Additional Thermal Trip protection for transformer. Schottky barrier diodes are employed for rectification with less voltage drop and power waste, thus eliminating the need for noisy, hot, cooling fans that are liable to fail.

5 year warranty
Reliable performance
Reproducible results
Versatile specifications
Safe to use
Unique, compact design
Robust build quality
Sealed easy touch switches
Stackable
Wipe clean
Safe on/off switch at rear of the unit
No cooling fans required
Carry handle
CE marked

Specifications:
Dimensions:- 208 mm x 155mm x 115mm (W x H x D)
Input voltage:- 230V 5%
Output Voltage: – continuously variable by rotary knob from 0 to 15V
Slightly smoothed DC (by 2200F output capacitor) gives practical r.m.s values of 0 -15V at no load.
